The air-conditioning condenser dust content test bench is specially designed for the detection of impurity residues in the core components of air conditioners (condensers, evaporators). It uses an intelligent simulation circulation system to accurately flush and collect particles to ensure product cleanliness and performance.
Brand :
HONGCEModel :
HC-ACPT001Certificate :
Calibration Certificate(cost additional)Product Origin :
ChinaPayment Method :
T/T,T/CRegular Packaging :
PlywoodAir Conditioner Condenser Dust Content Test Bench High Precision Particle Detection (10μm+) IEC 60529 Test Equipment
Product Introduction:
In the field of air conditioning manufacturing, the cleanliness of condensers and evaporators directly affects the performance of the equipment and the health of users. The condenser and evaporator test bench adopts dynamic cycle flushing technology to simulate the actual refrigeration system operating environment. Through high-precision sensors and intelligent control systems, it automatically completes the entire process of particle flushing, collection, and analysis.
International reference standards:
EN 60312: Performance test standard for household and commercial vacuum cleaners (dust concentration 550mg/m³, laser particle counting method).
IEC 60529: Enclosure protection grade (IP code), applicable to equipment dust and water resistance test specifications.
GB/T 16913-2008: Dust physical property test method (parallel disk electrode design).
GB 5170.18: Parameter verification method for environmental test equipment of electrical and electronic products (temperature, humidity, pressure accuracy requirements).
Product use:
Air conditioning component inspection: analysis of impurity residues inside condensers, evaporators, and compressors.
Quality control: factory cleanliness verification of key components on the production line.
R&D support: evaluation of dustproof performance of new materials or processes.
After-sales diagnosis: tracing the source of particle pollution in faulty air conditioners.
Technical parameters:
| Parameters | Specifications |
| Detection particle range | 10μm – 500μm |
| Flow adjustment range | 0-500 L/Hr |
| Maximum test pressure | 10 MPa (high pressure module can be customized to 20MPa) |
| Temperature control range | -30°C ~ +150°C (optional) |
| Power input | AC 220V ±10%, 50/60Hz |
| Equipment size | 1800×800×1600 mm(customizable according to product) |
| Weight | 300KG |
| Noise level | ≤60 dB(A) |
Test objects and test items:
Test objects:
Air conditioning condensers, evaporators, heat exchange tubes, compressor housings.
Automotive air conditioning systems, industrial refrigeration equipment components.
Test items
Number and distribution density of residual particles
Impurity composition analysis (metal chips, fibers, etc.)
Pressure resistance and sealing of the circulation system
Dust screen filtration efficiency
Detail pictures:
